Configuration Guide

All configuration files use YAML format. There are two parts to the configuration of this system:

• The Event Notification Server configuration — typically /etc/zm/zmeventnotification.yml

• The Machine Learning Detection Hook configuration — typically /etc/zm/objectconfig.yml

The ES comes with a sample ES config file which you should customize as fit. The sample config file is well annotated, so you really should read the comments to get an understanding of what each parameter does. Similarly, the ES also comes with a sample objectconfig.yml file which you should read as well if you are using hooks.

Note

If you are upgrading from an older version that used INI/JSON config files (zmeventnotification.ini, objectconfig.ini, secrets.ini, es_rules.json), the install.sh script will automatically migrate them to YAML. See Breaking Changes for details on the migration.

Secrets

Both zmeventnotification.yml and objectconfig.yml support a shared secrets mechanism that keeps passwords and tokens out of your main config files. This lets you share config files safely without exposing credentials.

Add a secrets key in the general section of either (or both) config files, pointing to a secrets file. Then reference any secret by prefixing its name with !.

For example, in /etc/zm/objectconfig.yml (or /etc/zm/zmeventnotification.yml):

general:
  secrets: /etc/zm/secrets.yml

  portal: "!ZM_PORTAL"
  user: "!ZM_USER"
  password: "!ZM_PASSWORD"

And /etc/zm/secrets.yml contains:

secrets:
  ZMES_PICTURE_URL: "https://mysecretportal/zm/index.php?view=image&eid=EVENTID&fid=objdetect&width=600"
  ZM_USER: myusername
  ZM_PASSWORD: mypassword
  ZM_PORTAL: "https://mysecretportal/zm"
  ZM_API_PORTAL: "https://mysecretportal/zm/api"

Any value starting with ! is treated as a secret token and replaced with the corresponding value from the secrets file.

Secret resolution is recursive — tokens are resolved throughout the entire config, including inside nested structures like ml_sequence and stream_sequence. For example, you can use !ALPR_KEY inside an ALPR model entry:

ml:
  ml_sequence:
    alpr:
      sequence:
        - alpr_key: "!ALPR_KEY"

Token matching is case-insensitive: !ZM_USER, !zm_user, and !Zm_User all match a secret named ZM_USER (or zm_user).

Note

Because ! triggers secret lookup, you cannot use a password beginning with ! directly in the config. Instead, create a token in your secrets file and reference it.

Event Server Configuration

The Event Server is configured via /etc/zm/zmeventnotification.yml.

Key Sections

The file is organized into these sections:

• general — secrets file path, base data path, ES control interface settings, skip_monitors

• network — WebSocket port and bind address

• auth — ZoneMinder user/password authentication and timeout

• fcm — Firebase Cloud Messaging for push notifications. Supports proxied delivery (default via fcm_v1_url) or direct delivery using a Google Service Account (fcm_service_account_file). Also controls replace_push_messages, fcm_android_priority, fcm_android_ttl, include_profile_in_push, and token storage

• mqtt — MQTT broker settings with optional TLS (one-way or mutual)

• ssl — SSL certificate/key for the WebSocket server

• push — third-party push API (e.g. Pushover) via api_push_script

• customize — event polling intervals, debug levels, picture URL, notification toggles

• hook — ML hook scripts, notification channel routing, max_parallel_hooks, tag_detected_objects, and user scripts

max_parallel_hooks (default 0 = unlimited) limits how many hook child processes can run concurrently. When the limit is reached, new events wait until a slot is free. This is useful for resource-constrained systems where too many simultaneous ML detections can cause OOM or GPU contention.

Complete Reference

Every key accepted by zmeventnotification.yml, grouped by YAML section.

general — app-level settings

Key	Default	Description
secrets	none	Path to secrets YAML file for !TOKEN substitution
base_data_path	/var/lib/zmeventnotification	Base path for data directories and scripts
use_escontrol_interface	no	Enable ES control interface for dynamic behaviour overrides
escontrol_interface_file	${base_data_path}/misc/escontrol_interface.dat	File to persist ES control admin overrides
escontrol_interface_password	none	Password for accepting control interface connections
restart_interval	7200	Auto-restart ES after this many seconds (0 = disable)
skip_monitors	none	Comma-separated monitor IDs to completely skip ES processing

network — WebSocket server

Key	Default	Description
port	9000	WebSocket listening port
address	[::]	Bind address (use 0.0.0.0 for all IPv4 interfaces)

auth — authentication

Key	Default	Description
enable	yes	Check username/password against ZoneMinder database
timeout	20	Authentication timeout in seconds

fcm — Firebase Cloud Messaging

Key	Default	Description
enable	yes	Enable FCM push notifications
use_fcmv1	yes	Use FCM V1 protocol (recommended)
replace_push_messages	no	Replace previous push for same monitor (collapses notifications)
token_file	${base_data_path}/push/tokens.txt	File to persist registered FCM tokens
date_format	%I:%M %p, %d-%b	strftime format for notification timestamps
fcm_android_priority	high	Android push priority (high or normal)
fcm_android_ttl	none	Android message TTL in seconds (omit for FCM default)
fcm_log_raw_message	no	Log full push message on the cloud function (debugging only)
fcm_log_message_id	NONE	Unique ID to identify your messages in cloud function logs
fcm_v1_key	(managed zmNinjaNG key)	Authorization key for the FCM cloud function proxy
fcm_v1_url	(managed zmNinjaNG URL)	URL of the FCM cloud function proxy
include_profile_in_push	no	Include profile name in push display (iOS subtitle, Android body append)
fcm_service_account_file	none	Path to Google service account JSON for direct FCM (bypasses proxy)

mqtt — MQTT messaging

Key	Default	Description
enable	no	Enable MQTT notifications
server	127.0.0.1	MQTT broker hostname or IP
topic	zoneminder	MQTT topic name
username	none	MQTT broker username
password	none	MQTT broker password
retain	no	Set retain flag on MQTT messages
tick_interval	15	MQTT keep-alive interval in seconds
tls_ca	none	Path to CA certificate (enables MQTT over TLS)
tls_cert	none	Path to client certificate (for mutual TLS)
tls_key	none	Path to client private key (for mutual TLS)
tls_insecure	no	Disable TLS peer verification

ssl — WebSocket SSL

Key	Default	Description
enable	yes	Enable SSL for the WebSocket server
cert	none	Path to SSL certificate file
key	none	Path to SSL private key file

push — third-party push API

Key	Default	Description
use_api_push	no	Enable third-party push notifications (e.g. Pushover)
api_push_script	none	Script to invoke for push (receives event ID, monitor ID, name, cause, type, image path)

customize — notification and display

Key	Default	Description
es_rules	none	Path to ES rules YAML file for custom notification routing
console_logs	no	Display log messages to console
es_debug_level	5	Debug verbosity level for ES messages
event_check_interval	5	Seconds between event polling checks
monitor_reload_interval	300	Seconds between monitor list reloads
read_alarm_cause	no	Read alarm cause from ZM (requires ZM >= 1.31.2)
tag_alarm_event_id	no	Append event ID to alarm notification title
use_custom_notification_sound	no	Use custom notification sound
include_picture	no	Include picture URL in push notifications
picture_url	none	URL template for event images (use EVENTID as placeholder)
picture_portal_username	none	Username for picture URL authentication
picture_portal_password	none	Password for picture URL authentication
send_event_start_notification	yes	Send notifications when events start
send_event_end_notification	no	Send notifications when events end
use_hooks	no	Master on/off switch for ML hooks

hook — ML hook configuration

Key	Default	Description
max_parallel_hooks	0	Maximum concurrent hook processes (0 = unlimited)
event_start_hook	none	Script to run when an event starts
event_end_hook	none	Script to run when an event ends
event_start_hook_notify_userscript	none	User script to run after event start hook completes
event_end_hook_notify_userscript	none	User script to run after event end hook completes
event_start_notify_on_hook_success	none	Notification channels when start hook returns 0 (web, fcm, mqtt, api, all, none)
event_start_notify_on_hook_fail	none	Notification channels when start hook returns 1
event_end_notify_on_hook_success	none	Notification channels when end hook returns 0
event_end_notify_on_hook_fail	none	Notification channels when end hook returns 1
event_end_notify_if_start_success	yes	Only send end notification if start notification was sent
use_hook_description	no	Use hook script output as notification text
hook_skip_monitors	none	Comma-separated monitor IDs to skip hooks for
hook_pass_image_path	none	Pass image storage path to hook script (requires ZM >= 1.33)
tag_detected_objects	no	Write detected labels as ZM Tags (requires ZM >= 1.37.44)

Detection Hook Configuration

The detection hooks are configured via /etc/zm/objectconfig.yml.

Key Sections

The file is organized into these sections:

• general — ZM portal/API credentials, data paths, debug images, import_zm_zones, tag_detected_objects, show_models

• push — direct FCM push notifications from zm_detect (Path 1 only, ZM 1.39.2+). See push_config below for setup details.

• remote — remote ML server (pyzm.serve) gateway URL, mode, credentials, fallback

• ml — the detection pipeline:

  • ml.stream_sequence — frame selection: frame_set, resize, retry settings

  • ml.ml_sequence.general — pipeline-wide settings: model_sequence, frame_strategy, disable_locks, match_past_detections, max_detection_size, aliases

  • ml.ml_sequence.<type> — per-type general + sequence lists for object, face, alpr, audio (see Machine Learning Hooks for full details)

• monitors — per-monitor overrides for wait, ml_sequence, stream_sequence, and zones (with detection_pattern and ignore_pattern)

Direct Push Notifications (push section)

The push section configures direct FCM push notifications from zm_detect — Path 1 only, requires ZM 1.39.2+. zm_detect reads registered tokens from ZM’s Notifications table via pyzmNg and sends push notifications through an FCM cloud function proxy after detection.

Setup steps:

1. Ensure ZoneMinder is 1.39.2+ (adds the Notifications REST API).

2. Set push.enabled to yes in objectconfig.yml. The cloud function URL and key are pre-configured with the managed zmNinjaNG defaults (same as the ES) — no additional configuration needed.

3. Register device tokens: client apps (e.g. zmNinjaNG) register FCM tokens via the ZM /api/notifications.json REST endpoint. Tokens are stored in ZM’s Notifications database table.

If you run your own FCM cloud function proxy, replace fcm_v1_url and fcm_v1_key with your own values.

zm_detect respects per-token monitor filtering, throttle intervals, and push state. Invalid tokens are automatically cleaned up.

By default, push notifications are only sent when detection finds a match. If you use external sensor triggers and want a push even when ML detects nothing, set push.send_push_on_no_match to yes. The event cause/reason (e.g. “External Motion”) is used as the notification text.

Complete Reference

Every key accepted by objectconfig.yml, grouped by YAML section. Keys not listed here will be logged as unrecognized and ignored.

Note

Several keys have been moved or removed in 7.x. See Breaking Changes for details on what changed and migration steps.

general — app-level settings

Consumed by zm_detect.py / utils.py:

Key	Default	Description
secrets	none	Path to secrets YAML file for !TOKEN substitution
base_data_path	/var/lib/zmeventnotification	Base path for model files and data directories
portal	""	ZoneMinder portal URL (e.g. https://zm.example.com/zm)
api_portal	""	ZoneMinder API URL (e.g. https://zm.example.com/zm/api)
user	none	ZoneMinder username
password	none	ZoneMinder password
allow_self_signed	yes	Accept self-signed SSL certificates
image_path	${base_data_path}/images	Directory for detection images and past-detection files
pyzm_overrides	{}	Dict of pyzmNg settings to override (e.g. log_level_debug)
wait	0	Seconds to sleep before running detection
show_percent	no	Show confidence percentage in detection output
show_models	no	Show model name in detection output (e.g. (YOLOv11) person)
show_frame_match_type	yes	Show frame match prefix in detection output: [a] (alarm), [s] (snapshot), [x] (other)
write_image_to_zm	yes	Write annotated image back to ZoneMinder event
write_debug_image	yes	Write a debug image with all detections to image_path
tag_detected_objects	no	Write detected labels as ZM Tags (requires ZM >= 1.37.44)
poly_color	(255,255,255)	RGB color for polygon overlays on annotated images
poly_thickness	2	Line thickness for polygon overlays (pixels)
import_zm_zones	no	Import zone definitions from ZoneMinder instead of using config zones
only_triggered_zm_zones	no	When yes, import only ZM zones that triggered the alarm (forces import_zm_zones: yes)

push — direct FCM push notifications

Direct push from zm_detect (Path 1 only, requires ZM 1.39.2+). See push_config above for setup steps.

Key	Default	Description
enabled	no	Enable direct FCM push notifications from zm_detect
fcm_v1_url	(managed zmNinjaNG URL)	URL of the FCM cloud function proxy. Replace only if you run your own.
fcm_v1_key	(managed zmNinjaNG key)	Authorization key for the cloud function proxy. Replace only if you run your own.
replace_push_messages	yes	Collapse notifications per monitor (replaces previous push)
include_picture	yes	Include event image URL in the notification
picture_url	none	Picture URL template (use EVENTID as placeholder for event ID)
picture_portal_username	none	Username for picture URL authentication
picture_portal_password	none	Password for picture URL authentication
include_profile_in_push	no	Include profile name in push display (iOS subtitle, Android body append)
send_push_on_no_match	no	Send push notification even when detection finds no matches. Useful for external sensor triggers where you want a notification regardless of ML results. The event cause/reason is used as the notification text.
android_priority	high	FCM priority for Android (high or normal)
android_ttl	none	Android message TTL in seconds (omit for FCM default)

remote — remote ML gateway settings

Forwarded to pyzmNg Detector:

Key	Default	Description
ml_gateway	none	URL of remote pyzm.serve instance (e.g. http://gpu:5000)
ml_gateway_mode	url	url (server fetches frames) or image (client sends JPEG)
ml_user	none	Username for remote gateway authentication
ml_password	none	Password for remote gateway authentication
ml_timeout	60	Gateway request timeout in seconds
ml_fallback_local	no	Fall back to local detection if remote gateway fails

ml.stream_sequence — frame extraction

Read by pyzmNg StreamConfig:

Key	Default	Description
frame_set	snapshot,alarm,1	Comma-separated list of frames to extract (snapshot, alarm, or numeric IDs)
resize	none	Resize frames to this width (pixels) before detection. Omit for original resolution.
max_frames	0	Maximum frames to extract (0 = no limit)
start_frame	1	First frame index to consider
frame_skip	1	Process every Nth frame
contig_frames_before_error	5	Contiguous frame errors before giving up
max_attempts	1	Retries per frame on failure
sleep_between_attempts	3	Seconds between retries
save_frames	no	Save extracted frames to disk
save_frames_dir	/tmp	Directory for saved frames
convert_snapshot_to_fid	no	When yes, resolve "snapshot" in frame_set to the event’s MaxScoreFrameId via the ZM API before fetching. Default no passes fid=snapshot through to ZM unchanged.

ml.ml_sequence.general — detection pipeline

Read by pyzmNg DetectorConfig:

Key	Default	Description
model_sequence	object	Comma-separated model types to run (object, face, alpr, audio)
frame_strategy	most_models	How to pick the best frame: most_models, first, first_new, most, most_unique
same_model_sequence_strategy	first	How to combine results from multiple models of the same type: first, most, most_unique, union
disable_locks	no	Disable file-based locking for model execution
match_past_detections	no	Deduplicate static objects across successive detections
past_det_max_diff_area	5%	Area difference threshold for past-detection matching
<label>_past_det_max_diff_area	—	Per-label override (e.g. car_past_det_max_diff_area: 10%)
ignore_past_detection_labels	[]	Labels to never deduplicate (e.g. ['dog', 'cat'])
max_detection_size	none	Maximum bounding box size to accept (pixels or percentage, e.g. 90%)
pattern	.*	Global regex pattern for accepted labels
aliases	[]	Groups of labels to treat as equivalent (e.g. [['car','bus','truck']])

ml.ml_sequence.<type> — per-type model settings

Each type (object, face, alpr, audio) has a general section for overrides and a sequence list of model configurations. See Machine Learning Hooks for details on model-specific keys (object_weights, face_detection_framework, alpr_service, etc.).

monitors — per-monitor overrides

Any key from the sections above can be overridden per monitor. Dict values (ml_sequence, stream_sequence) are deep-merged; scalar values are replaced. See Machine Learning Hooks for zone configuration (detection_pattern, ignore_pattern).

Configuration Tools

Several tools are provided in the tools/ directory of the source tree:

• tools/install_doctor.py — post-install diagnostic checker. Validates GPU/CUDA availability, OpenCV version, model file paths, file permissions, SSL certificates, and Perl/Python dependencies. Run automatically by install.sh at the end of installation. See Path 1: Detection + Optional Push (no ES) for usage.

• tools/config_migrate_yaml.py — migrates objectconfig.ini to objectconfig.yml

• tools/es_config_migrate_yaml.py — migrates zmeventnotification.ini and secrets.ini to their YAML equivalents

• tools/config_upgrade_yaml.py — merges new keys from example configs into your existing YAML config (used during upgrades to add new options without overwriting your settings)

• tools/config_edit.py — programmatic config editor

See Breaking Changes for details on the INI-to-YAML migration.
